Industrial Automation Products

ALLEN BRADLEY • RKD3500929

1492-L4Q-RE
TERMINAL BLOCK
SPRING CLAMP CONNECTION
FEED THROUGH WITH 2 CONNECTION POINTS 2 ON EACH SIDE
6.1 X 105 X 35.7MM (0.24 X 4.14 X1.41 IN)
1 POLE
RED
VOLTAGE RATING UR - 600V AC/DC
CSA - 600V AC/DC
IEC - 800V AC/DC
ATEX - 550V AC/D

ALLEN BRADLEY • RKD3500937

1492-L4-W
TERMINAL BLOCK
SPRING CLAMP CONNECTION
FEED THROUGH
6.1 X 62 X 35.7MM (0.24 X 2.44 X 1.41 IN)
1 POLE
WHITE
VOLTAGE RATING UR - 600V AC/DC
CSA - 600V AC/DC
IEC - 800V AC/DC
ATEX - 550V AC/DC
MAXIMUM CURRENT RATING UR - 33A
CS

ALLEN BRADLEY • RKD3500935

1492-L4T-B
TERMINAL BLOCK
SPRING CLAMP CONNECTION
1 POLE
BLUE
600 V AC/DC
800 V AC/DC
550 V AC

ALLEN BRADLEY • RKD3500931

1492-L4Q-W
ONE-CIRCUIT FEED-THROUGH BLOCK
2 CONNECTION POINTS ON EACH SIDE
4 MM MAX. WIRE
WHITE

ALLEN BRADLEY • RKD3500909

1492-L16
TERMINAL BLOCK
SPRING CLAMP CONNECTION
FEED THROUGH
10 X 73.5 X 43.5MM (0.394 X 2.89 X 1.71 IN)
1 POLE
GRAY
VOLTAGE RATING UR - 600V AC/DC
CSA - 600V AC/DC
IEC - 800V AC/DC
ATEX - 550V AC/DC
MAXIMUM CURRENT RATING UR - 65A
C

ALLEN BRADLEY • RKD3500919

1492-L3T1P
TERMINAL BLOCK
SPRING CLAMP
ONE-CIRCUIT FEED-THROUGH BLOCK
2.5 MM (# 22 AWG - # 14 AWG)
SINGLE-CIRCUIT TERMINAL BLOCK WITH 2 FIXEDAND 1 PLUG-IN CONNECTION
GRAY (STANDARD)

ALLEN BRADLEY • RKD3500927

1492-L4-G
TERMINAL BLOCK
SPRING CLAMP CONNECTION
FEED THROUGH
6.1 X 62 X 35.7MM (0.24 X 2.44 X 1.41 IN)
1 POLE
GREEN
VOLTAGE RATING UR - 600V AC/DC
CSA - 600V AC/DC
IEC - 800V AC/DC
ATEX - 550V AC/DC
MAXIMUM CURRENT RATING UR - 33A
CS

ALLEN BRADLEY • RKD3500925

1492-L4-BL
TERMINAL BLOCK
SPRING CLAMP CONNECTION
FEED THROUGH
6.1 X 62 X 35.7MM (0.24 X 2.44 X 1.41 IN)
1 POLE
BLACK
VOLTAGE RATING UR - 600V AC/DC
CSA - 600V AC/DC
IEC - 800V AC/DC
ATEX - 550V AC/DC
MAXIMUM CURRENT RATING UR - 33A
CS

ALLEN BRADLEY • RKD3500923

1492-L3T-RE
TERMINAL BLOCK
SPRING CLAMP CONNECTION
FEED THROUGH WITH 3 CONNECTION POINTS - 2 ON ONE SIDE
5.1 X 64.5 X 31.3MM (0.20 X 2.54 X1.23 IN)
1 POLE
RED0
VOLTAGE RATING UR - 600V AC/DC
CSA - 600V AC/DC
IEC - 800V AC/DC
ATEX - 550V A

ALLEN BRADLEY • RKD3500893

1492-JD4-W
TERMINAL BLOCK
SCREW CONNECTION
FEED THROUGH
TWO LEVEL - TWO CIRCUIT
6.1 X 60.7 X 57MM (0.24 X 2.39 X 2.24 IN)
1 POLE
WHITE0
VOLTAGE RATING UR - 600V AC/DC
CSA - 300V AC/DC
IEC - 800V AC/DC
ATEX - 550V AC/DC
MAXIMUM CURRENT RA

ALLEN BRADLEY • RKD3500913

1492-L2-B
TERMINAL BLOCK
SPRING CLAMP CONNECTION
FEED THROUGH
3.5X51.5X29.5MM (0.138X2.03X1.16 IN)
1 POLE
BLUE
VOLTAGE RATING UR - 300VAC/DC
CSA - 300VAC/DC
IEC - 500VAC/DC
ATEX - 550VAC/DC
MAXIMUM CURRENT RATING UR: 15A

ALLEN BRADLEY • RKD3500867

1492-J10-OR
TERMINAL BLOCK
SCREW CONNECTION
FEED THROUGH
9.9 X 60 X 39.5MM (0.39 X 2.36 X 1.56 IN)
1 POLE
ORANGE
VOLTAGERATING UR - 600V AC/DC
CSA - 600V AC/DC
IEC - 1000V AC/DC
ATEX - 550V AC/DC
MAXIMUM CURRENT RATING UR - 65A
CSA - 50

ALLEN BRADLEY • RKD3500917

1492-L3Q-OR
SUPPLEMENTARY PROTECTOR
ONE-CIRCUIT
FEED-THROUGH BLOCK
2 CONNECTION POINTS ON EACH SIDE
2.5MM MAX. WIRE
ORANGE

ALLEN BRADLEY • RKD3500907

1492-L10-RE
ONE-CIRCUIT FEED-THROUGH BLOCK
10 MM MAX. WIRE
RED

ALLEN BRADLEY • RKD3500875

1492-J4-BR
TERMINAL BLOCK
SCREW CONNECTION
FEED THROUGH
6.1 X 60 X 39.5MM (0.24 X 2.36 X 1.56 IN)
1 POLE
BROWN0
VOLTAGERATING UR - 600V AC/DC
CSA - 600V AC/DC
IEC - 800V AC/DC
ATEX 690V AC/DC
MAXIMUM CURRENT RATING UR - 35A
CSA - 25A

ALLEN BRADLEY • RKD3500889

1492-JD3-OR
TERMINAL BLOCK
SCREW CONNECTION
FEED THROUGH
TWO LEVEL - TWO CIRCUIT
5.1 X 69 X 55.5MM (0.20 X 2.72 X 2.19 IN)
1 POLE
ORANGE0
VOLTAGE RATING UR - 600V AC/DC
CSA - 300V AC/DC
IEC - 400V AC/DC
ATEX - 275V AC/DC
MAXIMUM CURRENT R

ALLEN BRADLEY • RKD3500905

1492K3Q
TERMINAL BLOCK
SINGLE CKT. IDC TERM. BLK.
2.5MM MAX. WIRE
W/QUAD CLAMP BLOCK
GRAY

ALLEN BRADLEY • RKD3500885

1492-J6FB2120
TERMINAL BLOCK
SCREW CONNECTION
FUSIBLE
LED BLOWN FUSE INDICATOR
7.9 X 60 X 61MM (0.31 X 2.36 X 2.41 IN)
1 POLE
BLACK
VOLTAGE RATING UR - 60-150V AC/DC
CSA - 60-150V AC/DC
IEC - 60-150V AC/DC
MAXIMUM CURRENT RATING UR - 10A
C

ALLEN BRADLEY • RKD3500895

1492-JDG3N
TERMINAL BLOCK
SCREW CONNECTION
THREE LEVEL WITH TWO FEED THROUGH AND GROUND CONNECTION
6.1 X 84 X 41.5MM (0.24 X 3.33 X 1.63IN)
1 POLE
GRAY
VOLTAGE RATING UR - 300V AC/DC
CSA - 300V AC/DC
IEC - 400V AC/DC
MAXIMUM CURRENT RATING

ALLEN BRADLEY • RKD3500903

1492-JTC3T
TERMINAL BLOCK
SCREW CONNECTION
2 CIRCUIT THERMOCOUPLE
1 CIRCUIT-E COPPER
1 CIRCUIT -A CONSTANTAN
10.2 X 60 X 43MM (0.40 X2.36 X 1.69 IN)
1 POLE
GRAY
55 V AC/DC
WIRE RANGE (RATED CROSS SECTION) V I

ALLEN BRADLEY • RKD3500901

1492-JTC3E
TERMINAL BLOCK
SCREW CONNECTION
2 CIRCUIT THERMOCOUPLE
1 CIRCUIT-CHROME
1 CIRCUIT -CONSTANT
10.2 X 60 X 43MM (0.40 X 2.36X 1.69 IN)
1 POLE
GRAY
55 V AC/DC
WIRE RANGE (RATED CROSS SECTION) IEC

ALLEN BRADLEY • RKD3500897

1492-JP3FB250
TERMINAL BLOCK
SCREW CONNECTION
DISCONNECT STYLE SINGLE-CIRCUIT FUSIBLE WITH LED BLOWN FUSE INDICATION
5.1 X 88 X 74MM (0.20 X3.46 X 2.91 IN)
1 POLE
BLACK
VOLTAGE RATING UR - 100...250V AC/DC
CSA - 100...250V AC/DC
IEC - 100...2

ALLEN BRADLEY • RKD3500887

1492-JD3
TERMINAL BLOCK
SCREW CONNECTION
FEED THROUGH
2CIRCUIT
5.1 X 69 X 55.5MM (0.20 X 2.72 X 2.19 IN)
GRAY
VOLTAGE RATING UR - 600VAC/DC
CSA - 300VAC/DC
IEC - 400VAC/DC
ATEX - 275VAC/DC
MAX CURRENT 20AMP
22-12AWG

ALLEN BRADLEY • RKD3500871

1492-J3-G
TERMINAL BLOCK
SCREW CONNECTION
FEED THROUGH
5.1 X 60 X 39.5MM (0.20 X 2.36 X 1.56 IN)
1 POLE
GREEN
VOLTAGERATING UR - 600V AC/DC
CSA - 600V AC/DC
IEC - 800V AC/DC
ATEX 550V AC/DC
MAXIMUM CURRENT RATING UR - 25A
CSA - 20A
