Industrial Automation Products

ALLEN BRADLEY • RKD3500901

1492-JTC3E
TERMINAL BLOCK
SCREW CONNECTION
2 CIRCUIT THERMOCOUPLE
1 CIRCUIT-CHROME
1 CIRCUIT -CONSTANT
10.2 X 60 X 43MM (0.40 X 2.36X 1.69 IN)
1 POLE
GRAY
55 V AC/DC
WIRE RANGE (RATED CROSS SECTION) IEC

ALLEN BRADLEY • RKD3500897

1492-JP3FB250
TERMINAL BLOCK
SCREW CONNECTION
DISCONNECT STYLE SINGLE-CIRCUIT FUSIBLE WITH LED BLOWN FUSE INDICATION
5.1 X 88 X 74MM (0.20 X3.46 X 2.91 IN)
1 POLE
BLACK
VOLTAGE RATING UR - 100...250V AC/DC
CSA - 100...250V AC/DC
IEC - 100...2

ALLEN BRADLEY • 36649 BX1731

1492-JD3
TERMINAL BLOCK
SCREW CONNECTION
FEED THROUGH
2CIRCUIT
5.1 X 69 X 55.5MM (0.20 X 2.72 X 2.19 IN)
GRAY
VOLTAGE RATING UR - 600VAC/DC
CSA - 300VAC/DC
IEC - 400VAC/DC
ATEX - 275VAC/DC
MAX CURRENT 20AMP
22-12AWG

ALLEN BRADLEY • RKD3500871

1492-J3-G
TERMINAL BLOCK
SCREW CONNECTION
FEED THROUGH
5.1 X 60 X 39.5MM (0.20 X 2.36 X 1.56 IN)
1 POLE
GREEN
VOLTAGERATING UR - 600V AC/DC
CSA - 600V AC/DC
IEC - 800V AC/DC
ATEX 550V AC/DC
MAXIMUM CURRENT RATING UR - 25A
CSA - 20A

ALLEN BRADLEY • RKD3500891

1492-JD3RB182
FEED-THROUGH BLOCK
IEC
2 CIRCUIT
TWO LEVEL BLOCK
WITH A SELECTABLE RESISTOR VALUE BETWEEN THE 2 LEVELS
4 MM MAX. WIRE
GRAY
1800 OHM RESISTANCE
OPEN STYLE
RAIL MOUNTABLE

ALLEN BRADLEY • RKD3500883

1492-J50
TERMINAL BLOCK
SCREW CONNECTION
FEED THROUGH
18.5 X 73.4 X 63.3MM (0.728 X 2.89 X 2.49 IN)
1 POLE
YELLOW
VOLTAGE RATING UR - 1000V AC/DC
CSA - 600V AC/DC
IEC - 1000V AC/DC
ATEX 690V AC/DC
MAXIMUM CURRENT RATING UR - 150A
CSA -

ALLEN BRADLEY • RKD3500879

1492-J4Q
TERMINAL BLOCK
SCREW CONNECTION
SPECIALITY FEED THROUGH WITH 2 CONNECTION POINTS ON EACH SIDE
6.1 X 69 X 46MM (0.24 X 2.72 X1.81 IN)
1 POLE
GRAY
VOLTAGE RATING UR - 600V AC/DC
CSA - 600V AC/DC
IEC - 500V AC/DC
MAXIMUM CURRENT R

ALLEN BRADLEY • RKD3500881

1492-J4TW
TERMINAL BLOCK
SCREW CONNECTION
SPECIALITY FEED THROUGH WITH 3 CONNECTION POINTS - 2 ON ONE SIDE
6.1 X 63 X 46MM (0.24 X 2.49 X1.81 IN)
1 POLE
GRAY
VOLTAGE RATING UR - 600V AC/DC
CSA - 600V AC/DC
IEC - 500V AC/DC
MAXIMUM CURREN

ALLEN BRADLEY • RKD3500873

1492-J4-B
TERMINAL BLOCK
BLUE
4 MM
FEED THROUGH
35 AMP
600 VOLTS

ALLEN BRADLEY • RKD3500865

1492-J10-G
TERMINAL BLOCK
SCREW CONNECTION
FEED THROUGH
9.9 X 60 X 39.5MM (0.39 X 2.36 X 1.56 IN)
1 POLE
GREEN
VOLTAGERATING UR - 600V AC/DC
CSA - 600V AC/DC
IEC - 1000V AC/DC
ATEX - 550V AC/DC
MAXIMUM CURRENT RATING UR - 65A
CSA - 50A

ALLEN BRADLEY • RKD3500869

1492-J3-B
TERMINAL BLOCK
SCREW CONNECTION
FEED THROUGH
1 POLE
BLUE
800 VAC/DC
20-25 AMP

ALLEN BRADLEY • RKD3500863

1492-IFM40F-F120-2
WIRING SYSTEMS MODULES
1492 SERIES
DIGITAL MODULE WITH FIXED TERMINAL BLOCK
40 PINS
FUSIBLE
SENSOR
120V AC
TWO PER I/O CONNECTION

ALLEN BRADLEY • RKD3500861

1492-IFM40DS24-4
WIRING SYSTEMS MODULES
1492 SERIES
DIGITAL MODULE WITH FIXED TERMINAL BLOCK
40 PINS
LED INDICATING
ISOLATED EXTRA TERMINALS FOROUTPUTS
24V AC/DC
FOUR PER I/O CONNECTION

ALLEN BRADLEY • RKD3500829

1492-HJ812
TERMINAL BLOCK
PANEL MOUNTED
12-POLE
25A
600V
UR/CSA
#16A#12 AWG
SCREW TERMINAL WITH WIRE CLAMP
WHITE

ALLEN BRADLEY • RKD3500837

1492-HM2RE
TERMINAL BLOCK
MULTI-RAIL MOUNTED
TWO-CKT
24A(IEC:30A)
600V
UR/CSA/CE
#30 - #12 AWG
FINGER-SAFE HIGH DENSITY
RED

ALLEN BRADLEY • RKD3500835

1492-HM2RB102
CONNECTION PRODUCTS
1000 OHM
MULTI-RAIL RESISTOR COMPONENT
METAL FILM
1/4 WATT
1 PCT

ALLEN BRADLEY • RKD3500833

1492-HM1R
TERMINAL BLOCK
MULTI-RAIL
1 POLE
30 AMP
RED
IEC
OPEN STYLE
DIN RAIL MOUNTABLE

ALLEN BRADLEY • RKD3500825

1492-H2Y
DISCONTINUED BY MANUFACTURER 12/31/2013
FINGER-SAFE TERMINAL BLOCK
RAIL MOUNT
TWO CIRCUIT
SCREW WITH PRESSURE PLATE
24 AMP
600V AC/DC
YELLOW
OPEN STYLE
MOUNTABLE

ALLEN BRADLEY • RKD3500827

X-177122
DISCONTINUED BY MANUFACTURER
DISCONNECT SWITCH
VISABLE CONTACT
30 AMP
440/550 VAC
SCREW TERMINAL

ALLEN BRADLEY • RKD3500831

1492-HM
DISCONTINUED BY MANUFACTURER
TERMINAL BLOCK
WHITE
OPEN STYLE
MOUNTABLE

ALLEN BRADLEY • RKD3500823

1492-H2VT
DISCONTINUED BY MANUFACTURER 12/31/2013
FINGER-SAFE TERMINAL BLOCK
RAIL MOUNT
TWO-CIRCUIT
SCREW WITH PRESSURE PLATE
600V AC/DC 24AMP RATING
VIOLET PLASTIC MATERIAL
#30-#12 AWG WIRE RANGE

ALLEN BRADLEY • RKD3500819

1492-H1296
FINGER-SAFE SINGLE CIRCUIT HIGH DENSITY BLOCK
SCREW W/ PRESSURE PLATE
#30 - #12 AWG
TWO 3'
RAILS (148/RAIL)
WHITE

ALLEN BRADLEY • RKD3500821

1492-H2GY
DISCONTINUED BY MANUFACTURER 12/31/2013
FINGER-SAFE TERMINAL BLOCK
RAIL MOUNT
TWO-CIRCUIT
SCREW WITH PRESSURE PLATE
24 AMP
600VAC/DC
GRAY
WIRE RANGE (RATED CROSS SECTION): #30-#12 AWG (0.05-4 MM2)
*** PRICED PER QTY. 1 ***

ALLEN BRADLEY • RKD3500804

X-176862
DISCONTINUED BY MANUFACTURER
CONTACT BLOCK
FOR SIZE 1
30 AMP
BULLETIN 894
