FESTO • RKD1703004

VMPAL-AP-20-T1
MPAL
VT TYPE 34
SUB-BASE

FESTO • RKD1538541

VMPAL-EG
PLATE
-0.9 BAR ... 10 BAR
DUCTED EXHAUST AIR
HIGH CORROSION STRESS

FESTO • RKD1634098

VMPAL-EPL-AP
END PLATE
VMPA SERIES
TOP CONNECTION POSITION
REVERSE POLARITY PROTECTED
32 VALVE POSITIONS MAX.
32 SOLENOID COILS MAX.
1.7 NM MAX. TIGHTENING TORQUE
8087171

FESTO • RKD1761013

VMPAL-EPL-CPX
END PLATE
LEFT-HANDED
CX ELECTRICAL CONNECTION
PNEUMATIC INTERFACE FOR CPX TERMINAL
32 ADDRESSES
3...8 BAR PILOT PRESSURE
-.9...10 BAR OPERATING PRESSURE
24VDC
HIGH CORROSION STRESS (3)

FESTO • RKD1761015

VMPAL-EPL-FB-POLY
DISCONTINUED BY MANUFACTURER
TERMINAL VALVE END PLATE

FESTO • RKD1822228

VMPAL-EPL-IPO32
END PLATE
SPARE PARTS
M12X1 A-CODED
PLUG CONNECTION
IO-LINK
IN MOUNTED STATE
24 VDC NOMINAL OPERATING VOLTAGE
(575667)

FESTO • RKD1703006

VMPAL-EPL-SD25
END PLATE
43 MM WIDTH
107.3 MM LENGTH
OPERATING PRESSURE: 0.9-10 BAR
PILOT PRESSURE: 3-8 BAR
24 VDC
MAX. NUMBER OF VALVE POSITIONS: 24
IP67

FESTO • RKD1634100

VMPAL-EPL-SD25-IP40
END PLATE
24 VALVE POSITIONS MAX.
24 SOLENOID COILS MAX.
-0.9-10 BAR OPERATING PRESSURE
25-PIN SUB-D CONNECTION
24 VDC
IP40
(560940)

FESTO • RKD1761018

VMPAL-EPL-SD44
END PLATE
VMPA SERIES
32 VALVE POSITIONS MAX.
32 SOLENOID COILS MAX.
-0.9-10 BAR OPERATING PRESSURE
3-8 BAR PILOT PRESSURE
SUB-D
44-PIN
PLUG CONNECTION
560939

FESTO • RKD1791273

VMPAL-EPR
END PLATE
RIGHT SIDE
FOR VALVE TERMINAL
ROHS COMPLIANT
DIE-CAST ALUMINUM
0.3-0.8 MPA PILOT PRESSURE
-0.09-1 MPA OPERATING PRESSURE

FESTO • RKD1538543

VMPAL-EPR-SP
END PLATE
RIGHT-HANDED
HIGH
WITH PORTS 1 - 3 - 5 - 12/14 - 82/84
WITH PILOT AIR SELECTOR FOR CHOOSING THE PILOT AIR SUPPLY
INTERNAL OR EXTERNAL
REVERSIBLE OPERATION POSSIBLE

FESTO • RKD1810462

VMPAL-EU
PLATE
VMPA SERIES
18.7 MM WIDTH
107.3 MM LENGTH
FLAT PLATE SILENCER
-0.9-10 BAR OPERATING PRESSURE
560955

FESTO • RKD1791278

VMPAL-EVAP-10-1
ELECTRICAL MANIFOLD MODULE
"
C"
MODULE BLOCK 1-40
FOR ONE SUB-BASE (1 VALVE POSITION)
SINGLE SOLENOID (1 SOLENOID COIL)
10MM VALVE SIZE
24VDC
GREY
HIGH CORROSION STRESS (3)

FESTO • RKD1791280

VMPAL-EVAP-10-2
ELECTRICAL MANIFOLD MODULE
"
A"
MODULE BLOCK 1-40
FOR ONE SUB-BASE (1 VALVE POSITION)
BLACK
DOUBLE SOLENOID (2 SOLENOID COILS)
34 PIN
24VDC
10 MM VALVE SIZE
HIGH CORROSION STRESS (3)

FESTO • RKD1538545

VMPAL-EVAP-10-2-4
ELECTRICAL MANIFOLD MODULE
VMPAL SERIES
10 MM VALVE SIZE
4 VALVE POSITIONS
8 SOLENOID COILS
24 VDC
(560968)

FESTO • RKD1761020

VMPAL-EVAP-14-1
ELECTRICAL MANIFOLD MODULE
VMPAL SERIES
14 MM VALVE SIZE
1 VALVE POSITION
1 SOLENOID COIL
24 VDC
560963

FESTO • RKD1761022

VMPAL-EVAP-14-2
ELECTRICAL MANIFOLD MODULE
24 VDC
1 VALVE POSITION
2 VALVE COILS
VALVE SIZE: 14 MM
BLACK
560964

FESTO • RKD1791282

VMPAL-EVAP-20-1
ELECTRICAL MANIFOLD MODULE
VMPAL SERIES
20 MM VALVE SIZE
1 VALVE POSITION
1 SOLENOID COIL
24 VDC
560965

FESTO • RKD1634102

VMPAL-EVAP-20-2
ELECTRICAL MANIFOLD MODULE
VMPAL SERIES
20 MM VALVE SIZE
1 VALVE POSITION MAX.
2 SOLENOID COILS MAX.
24 VDC
560966

FESTO • RKD1634104

VMPAL-EVAP-20-SP
ELECTRICAL MANIFOLD MODULE
"
U"
MODULE BLOCK 1-40
BLACK
FOR SUPPLY MODULE (SIGNALS ARE PASSED THROUGH)
24VDC
HIGH CORROSION STRESS (3)

FESTO • RKD1801703

VMPAL-F20-G1/4
ADAPTER
VMPAL SERIES
10 PACK SIZE
-0.9-10 BAR OPERATING PRESSURE
18 MM CARTRIDGE
G1/4 PNEUMATIC CONNECTIONS
573914

FESTO • RKD1634106

VMPAL-FSP-G1/4
ADAPTER
VMPA SERIES
10 PACK SIZE
-0.9-10 BAR OPERATING PRESSURE
PNEUMATIC CONNECTION 1: CARTRIDGE 20 MM
PNEUMATIC CONNECTION 2: G
572381

FESTO • RKD1761024

VMPAL-KM-S-SD44-IP67-10
CONNECTING CABLE
VMPA SERIES
CABLE WITH PLUG CONNECTION
10 M CABLE LENGTH
9.6 MM CABLE DIAMETER
PVC SHEATH MATERIAL
IP67
560427

FESTO • RKD1634108

VMPAL-KM-SD25-IP67-0
HOOD
VMPAL SERIES
CUSTOMIZABLE ELECTRICAL CONNECTION
5-13 MM APPROVED CABLE DIAMETER
IP67
560428
